Display
Panel Size: Wide Screen 24.0"(61.0cm) 16:9
Panel Backlight / Type : TN
True Resolution : 1920x1080 *
Display Viewing Area(HxV) : 531.36 x 298.89 mm
Display Surface Non-glare
Pixel Pitch : 0.2768mm
Brightness(Max) : 350 cd/㎡
Contrast Ratio (Max) : 1000:1
Viewing Angle (CR≧10) : 170°(H)/160°(V)
Response Time : 1ms (Gray to Gray)
Display Colors : 16.7M
Flicker free
Video Feature
Trace Free Technology : Yes
Color Temperature Selection : 4 Modes
Gamma adjustment : Yes (Support Gamma 1.8/2.2/2.5 )
GamePlus(modes) : Yes (Crosshair/Timer/FPS Counter/Display Alignment)
Low Blue Light : Yes
HDCP support : Yes
GameVisual :6 Modes(Scenery/Racing/Cinema/RTS/RPG/FPS/sRGB Modes)
I/O Ports
Signal Input : HDMI, DisplayPort
USB Port(s) : 3.0x2
Power Consumption
Power ON mode: <65W (measuring a screen brightness of 200 nits without audio/ USB/ Card reader connection)
Power Saving/Off mode: <0.5W
Voltage: 100-240V, 50/60Hz
Mechanical Design
Chassis Colors : Black
Tilt : +20°~-5°
Swivel : +60°~-60°
Pivot : 0°~+90°
Height Adjustment : 0~120 mm
VESA Wall Mounting : 100x100mm
Super Narrow Bezel Design : Yes
Security
Kensington lock
Dimensions
Phys. Dimension with Stand(WxHxD): 561.6x(418.2~538.2)x237.9 mm
Phys. Dimension without Stand(WxHxD): 561.6x329.7x70 mm
Box Dimension(WxHxD): 735x415x280 mm
Accessories
Power cord
Power adapter
DisplayPort cable
USB 3.0 cable
Quick start guide
HDMI cable
Support CD
Warranty Card
Compliance and Standards
BSMI, CB, CCC, CE, CEL level 1, CU, ErP, FCC, J-MOSS, KCC, PSE, RoHS, UL/cUL, VCCI, WEEE, WHQL (Windows 10, Windows 8.1, Windows 7), RCM, TUV Flicker-free , eStandby, TUV Low Blue Light
Note
*PG248Q supports 1920x1080 @ 144Hz (Overclock to 180Hz)
**Digital Signal Frequency:
HDMI:30~90KHz(H)/24~60Hz(V)
DisplayPort (Normal):67~166KHz(H)/30~144Hz(V)
DisplayPort (Overclock):67~212KHz(H)/30~180Hz(V)
